Technical characteristics

X-axis travel: 4200~8200mm. (Door width is more than 2800mm)

Base three-line rail (X axis). (M65 ball type or M55 roller type)

Y-axis two-line rail. (M65 roller type, three sliders per track)

Z-axis hard rail. (Optional wiring rail for Z axis, M65 roller type, three sliders per rail) Stepped beam. (Arch bridge structure)

The contact surface between the sliding seat and the head is 1150mm long.

BT50, 4000rpm (6000rpm, 8000rpm) gear type spindle.
