Technical characteristics

High rigidity roller slide

X, Y, and Z all adopt high-load, high-precision, low-friction roller linear rails, combined with multiple sliders to increase the load capacity of the machine, to ensure the rigidity of the feed, and to maintain the machining accuracy and life for a long time.

High rigidity door beam structure design

The use of high-rigidity columns and widening at the base of the double-pillars to strengthen the rigidity, providing good rigidity and vibration damping performance, with excellent chip removal rate and high processing accuracy.

High-performance five-axis blunt head

The C-axis is directly driven by a torque motor, and the B-axis is driven by a servo motor through a backlash-free transmission system to reduce the volume of the head and reduce the possibility of interference. Both rotating shafts are equipped with an annular optical scale and equipped with a hydraulic brake system to ensure rigidity during positioning angle processing.

Z-axis four-roller linear guide

Ensure the rigidity of the head overhang during processing.

Folding sliding door

Simple and fast loading and unloading of workpieces, safe and convenient.

Ergonomic large rotating operation box

The user-friendly operation interface, the double rotating shaft arm covers a large area, and can be pulled into the work area for precise operation.

Large chip removal chip removal system

It is composed of screw chip remover on both sides and crawler chip remover, with high speed and high efficiency.
