Technical characteristics

High rigidity linear slide

The roller-type linear rail design with high rigidity, high precision and large span is adopted to increase the axial movement speed and ensure the rigidity of the feed.

Large slider design

The X-axis single track adopts a large slider configuration to ensure long-term machining accuracy and track life.

X, Y axis single side double servo drive motor

X-axis stroke above 5000mm (inclusive) and Y-axis above 3500mm (inclusive), using rack drive

X axis has four, Y axis has two servo drive motors

Using motor preload to eliminate backlash

The gear transmission mechanism of this wheel is equipped with clean and lubricated gears that act synchronously beside each moving gear.
